Outstanding Value and Performance
High Performance, Long Warranty
|
For the enthusiast
|
For the professional
|
Storage on the Go
|
 |
|
|
|
|
Samsung 860 Evo
2.5-inch SATA | mSATA | M.2 SATA
|
Samsung 860 Pro
2.5-inch SATA |
Samsung 970 Evo
M.2 PCIe NVMe |
Samsung 970 Pro
M.2 PCIe NVMe |
Samsung T5
USB 3.1 Gen 2 |
| Ideal For |
Every day usage in laptop and desktop computers
|
High Endurance and Professional applications
|
Where maximum speed counts
|
For maximum speed and endurance
|
High speed data transfers
|
|
Sequential Read
|
Up to 550MB/s
|
Up to 560MB/s
|
250 GB, 500GB, 1TB: Up to 3,400 MB/s
2TB: Up to 3,500 MB/s
|
Up to 3,500MB/s
|
Up to 540MB/s
|
|
Sequential Write
|
Up to 520MB/s
|
Up to 530MB/s
|
250 GB: Up to 1,500 MB/s
500 GB: Up to 2,300 MB/s
1TB, 2TB: Up to 2,500 MB/s
|
512 GB: Up to 2,300 MB/s
1TB: Up to 2,700 MB/s
|
Up to 515 MB/s
|
|
Random Read (QD1)
|
Max. 10K IOPS
|
Max. 11K IOPS
|
Max. 15K IOPS
|
Max. 15K IOPS
|
N/A
|
|
Random Read (QD32)
|
Max. 98K IOPS
|
Max. 100K IOPS
|
Max. 200K (250GB)
Max. 370K IOPS (500GB)
Max. 500K IOPS (1TB, 2TB)
|
Max. 370K IOPS (512GB)
Max. 500K IOPS (1TB)
|
N/A
|
|
Random Write (QD1)
|
Max. 42K IOPS
|
Max. 43K IOPS
|
Max. 50K IOPS
|
Max. 55K IOPS
|
N/A
|
|
Random Write (QD32)
|
Max. 90K IOPS
|
Max. 90K IOPS
|
Max. 350K IOPS (250GB)
Max. 450K IOPS (500GB, 1TB)
Max. 480K IOPS (2TB)
|
Max. 500K IOPS (512GB, 1TB)
|
N/A
|
|
Form Factor / Capacity
|
2.5" 7mm SATA |
250GB/500GB
1TB/2TB/4TB
|
2.5" 7mm SATA |
256GB/512GB
1TB/2TB/4TB
|
M.2 PCIe NVMe |
250GB/500GB/1TB/2TB
|
M.2 PCIe NVMe |
512GB/1TB
|
USB Storage Drive |
250GB/500GB/1TB/2TB
|
mSATA 50mm |
250GB/500GB/1TB
|
|
|
|
|
|
|
|
|
| M.2 SATA 2280 |
250GB/500GB/1TB
|
|
|
|
|
|
|
|
|
|
Interface
|
SATA 6Gb/s
|
SATA 6Gb/s
|
PCIe 3.0 x4, NVMe 1.3
|
PCIe 3.0 x4, NVMe 1.3
|
USB 3.1 Gen 2 (Type-A or Type-C)
|
|
NAND
|
Samsung 64 layer 3D V-NAND |
Samsung 64 layer 3D V-NAND |
Samsung 64 layer 3D 3-bit TLC V-NAND |
Samsung 64 layer 3D 2-bit MLC V-NAND |
Samsung 64 layer 3D 3-bit TLC V-NAND |
|
Controller
|
Samsung MJX
|
Samsung MJX
|
Samsung Phoenix
|
Samsung Phoenix
|
Samsung MGX
|
|
Active Power Consumption
|
4W |
3.3W-4.5W |
250GB: 5.5W
500GB: 5.7W
1TB/2TB: 6W |
512GB: 5.2W
512GB: 5.7W |
N/A |
|
Idle Power Consumption
|
50mW |
40mW |
30mW |
30mW |
N/A |
|
Devslp / L1.2 Power Consumption
|
2mW |
2mW |
5mW |
5mW |
N/A |
|
Trim Support
|
|
|
|
|
|
|
S.M.A.R.T Support
|
|
|
|
|
|
|
GC (Garbage Collection)
|
|
|
|
|
|
AES 256-bit encryption |
|
|
|
|
|
|
TCG Opal 2.0 compliant
|
|
|
|
|
|
| Adaptive Thermal Protection |
|
|
|
|
|
| Power loss protection |
|
|
|
|
|
|
Reliability (MTBF)
|
1.5 Million Hours |
2 Million Hours |
1.5 Million Hours |
1.5 Million Hours |
1.5 Million Hours |
|
Limited warranty
|
5-year (Client PC use only)*** |
5-year (Client PC use only)*** |
5-year (Client PC use only)*** |
5-year (Client PC use only)*** |
3-year (Client PC use only)*** |
|
Endurance / TBW (Terabytes Written)
|
250GB: 150TBW (82GB/day)
500GB: 300TBW (164GB/day)
1TB: 600TBW (328GB/day)
2TB: 1200TBW (656GB/day)
4TB: 2400TBW (1.3TB/day) |
256GB: 300TBW (164GB/day)
512GB: 600TBW (328GB/day)
1TB: 1200TBW (656GB/day)
2TB: 2400TBW (1.3TB/day)
4TB: 4800TBW (2.6TB/day) |
250GB: 150TBW (82GB/day)
500GB: 300TBW (164GB/day)
1TB: 600TBW (328GB/day)
2TB: 1200TBW (656GB/day) |
512GB: 600TBW (328GB/day)
1TB: 1200TBW (657GB/day) |
N/A |
*** The limited warranty assumes that the total bytes written (TBW) does not exceed the specification of the SSD. (calculated based on host writes and on the industry standard of 3 months data retention). Workloads that results in TBW exceeding the specification are not covered under warranty. Talk to a RamCity staffer about products with higher endurance features for enterprise applications if you are not sure if this product is right for you.
